Basic parameters

Dimensions: 400mm * 300mm * 290mm

Compatible with bullet type: 60mm size

Net weight: Six tubes weighing 2.5kg

Material: aviation aluminum, carbon fiber, stainless steel material

Installation method: Lock tongue upward impact automatic locking

Launch method: automatic single shot throwing

Caliber size: compatible with 60mm mortar shells

Loading capacity: 6 pieces

Power supply mode: onboard power supply

Working voltage: DC 12-60V

Control mode: SBUS signal 9-14 channels; Or independent 6-channel PWM

Control throwing accuracy: 1-3m

Control distance: 5-10km

Expanding caliber: customizable development of various caliber controllers such as 60mm

Camera pixel: 4k visible light

Onboard aiming function: equipped with one click downward aiming and cross cursor indication
